رله الکترومکانیکی

TIANBO
HJR-4102E-L-05V

Coil:5VDC

3A 120VAC

3A 24VDC

Contact Data:
Contact Form 1A,1B,1C
Contact Rating A: 20A 16VDC Resistive
B, C: 15A 16VDC Resistive
Max.Switching Voltage 30VDC
Max.Switching Current 35A
Max.Switching Power 280W
Min.Switching Load –
Coil Data:
Coil Voltage 6～24VDC
Coil Power 0.6W
0.8W
General Data:
Dielectric Strength Open Contacts 550VAC, 1min
Coil and Contacts 550VAC, 1min
Electrical Life(ops.) 100,000
Operating Temperature -40℃ to +85℃
Terminal Type PCB

Relay Type: General Purpose
Contact Form: SPST-NO (1 Form A)
Contact Rating (Current): 8A Max
Switching Voltage: 250VAC, 30VDC – Max
Coil Type: Non Latching
Coil Current: 30mA
Coil Voltage: 24VDC
Turn On Voltage (Max): 9 VDC
Turn Off Voltage (Min): 0.6 VDC
Mounting Type: Through Hole
Termination Style: PC Pin
Packaging: Bulk

Switching capacity: 20A
Dielectric strength of 5000V between
coil and contacts
Available in PCB or quick connect
terminals
Ideal for switching magnetron and
heater loads in microwave oven
Dimension: 24.2×12.3×20.1(mm)

Outline Dimension(L×W×H): 19×15.5×15.5
Dielectric Strengh Between Open Contact: 750VAC
Contact Form: 1A,1B,1C
Between Coil and Contact: 1500VAC
Contact Resistance: 100 mΩ
Coil Voltage: 5VDC ~ 48VDC
Electrical: 10^5
Mechanical: 10^7
Pick-up Voltage: ≤75%
Temperature Range: -40~ +70℃
Release Voltage: ≥10%
Coil Power(W): 0.36
Mounting Form: PCB Terminal
Contact Rating: 10A/15A 120VAC
7A 240VAC
10A 28VDC
Weight: 10g
Insulation Resistance: 100 MΩ
Safty Approval: UL

Coil voltage: 12VDC
Contact Rating: 240VAC/28VDC/15
Coil resistance: 360ohm
Contact: 1 x inverter
Nominal power consumption: 450 mW
Compact and lightweight design
Low coil power consumption Specifications
Dielectric strength: 1000 V / 50 Hz (1 minute)
Temperature range: -40 ° F to 158 ° F
Internal contact material: agcd
Miniature Power Relay is commonly used in home appliances, automatic control systems, electronic equipment, instruments, and meters.

Coil voltage: 24VDC
Contact Rating: 240VAC/28VDC/15
Coil resistance: 360ohm
Contact: 1 x inverter
Nominal power consumption: 450 mW
Compact and lightweight design
Low coil power consumption Specifications
Dielectric strength: 1000 V / 50 Hz (1 minute)
Temperature range: -40 ° F to 158 ° F
Internal contact material: agcd
Miniature Power Relay is commonly used in home appliances, automatic control systems, electronic equipment, instruments, and meters.

Manufacturer: LTonic
Series: Liming
Pin Arrangement: T91
Model: JQX-4501F
Coil Voltage: 24VDC
Coil Resistance: 650ohm
Contact Rating: NC: 20A 240VAC/28VDC
NO: 30A 240VAC/28VDC
electrical endurance of contacts – 100,000 times
dielectric strength between open contacts – 1000 V rms / per 1 min
dielectric strength between coil and contacts – 1500 V rms / per 1 min
operating temperature – from -45°C to + 70°C
dimensions – 32 x 27 x 28 mm

HKP

JQC-3FP (T73)

Coil:12VDC

10A 24VDC

10A 240VAC

Coil voltage: 12VDC
Contact Rating:
240VAC/10A
28VDC/15A
Contact: 1 x inverter
Nominal power consumption: 450 mW
Compact and lightweight design
Low coil power consumption Specifications
Temperature range: -40 ° C to 85 ° C
Internal contact material: agcd
Miniature Power Relay is commonly used in home appliances, automatic control systems, electronic equipment, instruments, and meters

Manufacturer: Song Chuan
Product Category: General Purpose Relays
Product: Power Relays
Type: Miniature
Coil Voltage: 12 VDC
Relay Contact Form: 1 Form A (SPST-NO)
Contact Current Rating: 17 A
Mounting Style: Through Hole
Switching Voltage: 277 VAC
Coil Termination: Solder Pin
Series: 888
Brand: Song Chuan
Length: 29 mm
Width: 12.7 mm
Height: 15.7 mm

Manufacturer: Song Chuan
Product Category: General Purpose Relays
RoHS: Details
Product: Power Relays
Coil Voltage: 9VDC
Contact Power Rating: 250VAC/10A-125VAC/15A
Relay Contact Form: 1 Form C (SPDT-NO, NC)
Contact Termination: Quick Connect Terminal
Mounting Style: Socket
Coil Termination: Quick Connect Terminal
Coil Resistance: 400Ohms
Contact Material: Silver Tin Oxide (AgSnO)
Series: 8301H
Length: 22.5 mm
Width: 16.5mm
Height: 20.3mm

Rated load: 8 A at 250 VAC, 8 A at 30 VDC
Rated carry current: 8 A
Max. switching voltage: 250 VAC
Max. switching current: 10 A
Max. switching capacity: 1250 VA

TIANBO
HJR-4102-L-12V

Coil:12VDC

3A 120VAC

3A 24VDC

Outline Dimension(L×W×H): 19×15.5×15.5
Dielectric Strengh Between Open Contact: 750VAC
Contact Form: 1A,1B,1C
Between Coil and Contact: 1500VAC
Contact Resistance: 100 mΩ
Coil Voltage: 5VDC ~ 48VDC
Electrical: 10^5
Mechanical: 10^7
Pick-up Voltage: ≤75%
Temperature Range: -40~ +70℃
Release Voltage: ≥10%
Coil Power(W): 0.36
Contact transfer Current(A): 15A
Mounting Form: PCB Terminal
Contact Rating: 10A 120VAC
7A 240VAC
10A/15A 28VDC
Weight: 10g
Insulation Resistance: 100 MΩ

TIANBO
HJR-4102-L-05V

Coil:5VDC

3A 120VAC

3A 24VDC

TIANBO

TR5V-L-S-Z 12VDC
Contact Form 1C

Glass : Length: 14mm
Glass : Diameter: 2mm
Total length : 43mm
Contact: Normal Open
Maximum switching voltage : 300 VDC
Minimum breakdown voltage : 150 VDC
Maximum contact rating : 10W
Maximum switching current : 0.55 A
Maximum operate time : 0.45 ms
Bounce time : 0.25 ms
Maximum release time : 0.35 ms
Resonant frequency : 5000 HZ
Maximum operating frequency : 400 HZ
Pull in value : 20-70 AT
Minimum drop out value : 4 AT
Maximum contact capacitance : 0.5 pF

HJR1-2CL-12V

1A 120VAC

2A 24VDC

HJR1-2CL-05V

1A 120VAC

2A 24VDC

Outline Dimension(L×W×H): 19×15.5×15.5
Dielectric Strengh Between Open Contact: 750VAC
Contact Form: 1A,1B,1C
Between Coil and Contact: 1500VAC
Contact Resistance: 100 mΩ
Coil Voltage: 5VDC ~ 48VDC
Electrical: 10^5
Mechanical: 10^7
Pick-up Voltage: ≤75%
Temperature Range: -40~ +70℃
Release Voltage: ≥10%
Coil Power(W): 0.36
Mounting Form: PCB Terminal
Contact Rating: 10A 120VAC
7A 240VAC
10A/15A 28VDC
Weight: 10g
Insulation Resistance: 100 MΩ
Safty Approval: UL

Outline Dimension(L×W×H): 19×15.5×15.5
Dielectric Strengh Between Open Contact: 750VAC
Contact Form: 1A,1B,1C
Between Coil and Contact: 1500VAC
Contact Resistance: 100 mΩ
Coil Voltage: 5VDC ~ 48VDC
Electrical: 10^5
Mechanical: 10^7
Pick-up Voltage: ≤75%
Temperature Range: -40~ +70℃
Release Voltage: ≥10%
Coil Power(W): 0.36
Mounting Form: PCB Terminal
Contact Rating: 10A/15A 120VAC
7A 240VAC
10A 28VDC
Weight: 10g
Insulation Resistance: 100 MΩ
Safty Approval: UL

HJR1-2CL-24V

1A 120VAC

2A 24VDC

Outline Dimension(L×W×H): 15.7×12.3×14
Dielectric Strengh: Between Open Contact 500VAC
Between Coil and Contact: 500VAC
Contact Form: 1A,1C
Contact Resistance: < 50 mΩ
Coil Voltage: 24VDC
Mechanical: 10^7
Electrical 10^5
Pick-up Voltage: ≤65%
Temperature Range: -40~ +85℃
Release Voltage: ≥10%
Coil Power(W): 0.6W,0.8W
Mounting Form: PCB Terminal
Contact Rating: NO:20A 14VDC 10A 120VAC
NC:15A 14VDC 10A 120VAC
Weight: 6g
Insulation Resistance: 100 MΩ
Safty Approval: UL,TUV

Outline Dimension(L×W×H): 15.7×12.3×14
Dielectric Strengh: Between Open Contact 500VAC
Between Coil and Contact: 500VAC
Contact Form: 1A,1C
Contact Resistance: < 50 mΩ
Coil Voltage: 5VDC
Mechanical: 10^7
Electrical 10^5
Pick-up Voltage: ≤65%
Temperature Range: -40~ +85℃
Release Voltage: ≥10%
Coil Power(W): 0.6W,0.8W
Mounting Form: PCB Terminal
Contact Rating: NO:20A 14VDC 10A 120VAC
NC:15A 14VDC 10A 120VAC
Weight: 6g
Insulation Resistance: 100 MΩ
Safty Approval: UL,TUV

Manufacturer: Song Chuan
Product Category: General Purpose Relays
Product: Power Relays
Type: Miniature
Coil Voltage: 9 VDC
Relay Contact Form: 1 Form A (SPST-NO)
Contact Power Rating: 125VAC/3A
Mounting Style: Through Hole
Coil Termination: Solder Pin
Coil Resistance: 255 Ohms
Contact Material: Silver Alloy (Ag)
Series: 842
Power Consumption: 850 mW

Manufacturer: Song Chuan
Product Category: General Purpose Relays
RoHS: Details
Product: Power Relays
Coil Voltage: 3VDC
Contact Power Rating: 250VAC/7A-277VAC/10A
Relay Contact Form: 1 Form C (SPDT-NO, NC)
Contact Termination: Quick Connect Terminal
Mounting Style: Socket
Coil Termination: Quick Connect Terminal
Contact Material: Silver Alloy (Ag)
Series: 833H
Length: 15.5 mm
Width: 19 mm
Height: 15 mm
Contact Form: SPDT (1 Form C)
Power Consumption: 360 mW
Brand: Song Chuan
Product Type: General Purpose Relays

ontact form: DPDT
Coil voltage: 48VDC
Contact rating: 12A @ 30VDC / 12A @ 240VAC
Coil Resistance: 3900Ω
Coil current: 28mA
Silver-Cadmium Oxide
PCB Terminal
No lamp
Standard mating socket: P/N (175531)
DIN rail mating socket: P/N (282191)

Manufacturer: Song Chuan
Product Category: General Purpose Relays
RoHS: Details
Product: Power Relays
Coil Voltage: 5VDC
Contact Power Rating: 250VAC/12A-277VAC/17A
Relay Contact Form: 1 Form A (SPST-NO)
Contact Termination: Quick Connect Terminal
Mounting Style: Socket
Coil Termination: Quick Connect Terminal
Series: 507
Length: 29 mm
Width: 12.5 mm
Height: 15.7 mm

Nominal switching capacity (resistive load): 1 A 30 V DC, 0.5 A 125 V AC
Max. switching power(resistive load): 30 W, 62.5 VA
Max. switching voltage: 110 V DC, 125 V AC
Max. switching current: 1 A
Min. switching capacity: 10 uA 10 mV DC
Nominal operating power: 2 coil latching: 110 mW (3 to 12 V DC) 200 mW (24 V DC)

Contact Resistance: 50ohm
max switching power: 60W/125VA
max switching voltage: 250VAC
max switching current: 2A
max carrying current: 3A
dimensions: 35x10x10mm

Manufacturer: Omron
Product Category: General Purpose Relays
RoHS: Details
Product: Power Relays
Type: Miniature
Coil Voltage: 12 VDC
Relay Contact Form: 1 Form A (SPST-NO), 1 Form B (SPST-NC)
Mounting Style: Through Hole
Coil Type: Non-Latching
Coil Resistance: 480 Ohms
Coil Current: 16.7 mA
Contact Material:Silver Alloy (Ag)
Series: G6B
Contact Form: SPST (1 Form A), SPST (1 Form B)
Power Consumption: 200 mW
Brand: Omron Electronics
Product Type: General Purpose Relays
